38 Tracer AdaptiView Display Operations Guide • CTV-SVU01B-EN
Equipment Settings
Chiller Setting
Tab l e 7 lists the settings that are available as buttons on the Chiller Settings menu screen,
along with their corresponding setting options. The chiller configuration determines
which of the settings appear.
Table 7. Chiller Settings menu screen: Buttons and available setting options
Buttons Available setting options
Setpoint Source • BAS/Ext/FP
•Ext/FP
• Front Panel
Front Panel Control Type • Chilled Water
•Hot Water
Active Chilled Water Setpoint
(a)
Valid numerical range appears on screen.
Active Hot Water Setpoint
(a)
Valid numerical range appears on screen.
Front Panel Ice Building Command • Auto
•On
Active Ice Termination Setpoint
(a)
Valid numerical range appears on screen.
Ice to Normal Cooling Timer Valid numerical range appears on screen.
Active Current Limit Setpoint
(a)
Valid numerical range appears on screen.
Front Panel Free Cooling Command • Auto
•On
Active Base Loading Setpoint
(a)
Valid numerical range appears on screen.
Front Panel Base Load Cmd • Auto
•On
Differential to Start Valid numerical range appears on screen.
Differential to Stop Valid numerical range appears on screen.
Evaporator Leaving Water Temperature Cutout Valid numerical range appears on screen.
Evaporator Refrigerant Temperature Cutout Valid numerical range appears on screen.
Condenser Water Pump Off Delay Valid numerical range appears on screen.
Evaporator Water Pump Off Delay Valid numerical range appears on screen.
Evaporator Low Water Flow Warning Setpoint Valid numerical range appears on screen.
Maximum Capacity Limit Valid numerical range appears on screen.
Minimum Capacity Limit Valid numerical range appears on screen.
Check Oil Filter Setpoint Valid numerical range appears on screen.
Capacity Control Softload Time Valid numerical range appears on screen.
Current Limit Control Softload Time Valid numerical range appears on screen.
Current Limit Control Softload Start Point Valid numerical range appears on screen.
Local Atmospheric Pressure Valid numerical range appears on screen.
