44 Tracer AdaptiView Display Operations Guide • CTV-SVU01B-EN
Equipment Settings
Manual Control Settings
Table 12, p. 44, lists the settings that are available as buttons on the Manual Control
Settings menu screen, along with their corresponding setting options. The chiller
configuration determines which of the settings appear.
Table 12. Manual Control settings menu screen: Buttons, available setting options, and status points
Feature Current value Available setting options Status points
Compressor Control Signal Auto/Manual Manual mode: Up/down
arrows for changing the
setpoint
IGV1 Position
IGV2 Position
Average Line Current
AFD Frequency
Active Chilled Water Setpoint (Active Hot Water
Setpoint if in Heating mode)
Evap Leaving Water Temp (Cond Leaving Water
Temp if in Heating mode)
Evap Water Pump On/Off • Auto
•On
Evaporator Pump Manual Override Time
Remaining
Evap Water Flow Switch Status
Active Chilled Water Setpoint
Evap Leaving Water Temp
Cond Water Pump On/Off • Auto
•On
Condenser Pump Manual Override Time
Remaining
Cond Water flow Switch Status
Active Hot Water Setpoint
Cond Leaving Water Temp
Clear Energy Consumption XXXX kWh Clear
Oil Pump On/Off • Auto
•On
Oil Pump Manual Override Time Remaining
Oil Differential Pressure
Oil Pump Discharge Pressure
Oil Tank Pressure
Clear Restart Inhibit Timer XX:XX min:sec Clear
Purge Exhaust Circuit Test Off/On • Auto
•On
Purge Rfgt Cprsr Suction Temp
Purge Liquid Temp
Purge Regen Cycle Off/On • Auto
•On
Carbon Tank Temp
