I/O Wiring
BMTW-SVN01F-EN 39
Table 5. Jumper Configurations, Operating Ranges, and Circuit Characteristics for Input Device Types
UIP1 (TB1-3 and TB1-4)
Input Device Jumper Pins on P10 Operating Range Circuit Characteristics
Binary/Pulse meter 2 and 3 10 mA, 10 V < 50 Ω = switches closed
> 1,000 Ω = switches open
Thermistor 1 and 2 –30°F to 220°F
(–34°C to 104°C)
10,000 Ω = 77°F (25°C)
Current 5 and 6 0–20 mA Input impedance < 500 Ω
Voltage 4 and 5 0–10 Vdc Input impedance > 500 Ω
UIP2 (TB1-5 and TB1-6)
Input Device Jumper Pins on P11 Operating Range Circuit Characteristics
Binary/Pulse meter 2 and 3 10 mA, 10 V < 50 Ω = switches closed
> 1,000 Ω = switches open
Thermistor 1 and 2 –30°F to 220°F
(–34°C to 104°C)
10,000 Ω = 77°F (25°C)
Current 5 and 6 0–20 mA Input impedance < 500 Ω
Voltage 4 and 5 0–10 Vdc Input impedance > 500 Ω
UIP3 (TB1-7 and TB1-8)
Input Device Jumper Pins on P12 Operating Range Circuit Characteristics
Binary/Pulse meter 2 and 3 10 mA, 10 V < 50 Ω = switches closed
> 1,000 Ω = switches open
Thermistor 1 and 2 –30°F to 220°F
(–34°C to 104°C)
10,000 Ω = 77°F (25°C)
Current 5 and 6 0–20 mA Input impedance < 500 Ω
Voltage 4 and 5 0–10 Vdc Input impedance > 500 Ω
UIP4 (TB1-9 and TB1-10)
Input Device Jumper Pins on P13 Operating Range Circuit Characteristics
Binary/Pulse meter 2 and 3 10 mA, 10 V < 50 Ω = switches closed
> 1,000 Ω = switches open
Thermistor 1 and 2 –30°F to 220°F
(–34°C to 104°C)
10,000 Ω = 77°F (25°C)
Current 5 and 6 0–20 mA Input impedance < 500 Ω
Voltage 4 and 5 0–10 Vdc Input impedance > 500 Ω
