Placement of rating plate and electrical wiring diagram
07/2019 244156V03_EN 17
2.7 Placement of rating plate and electrical wiring diagram
DANGER
Risk of fatal injury from electric shock!
The wiring diagram is located behind the rear cover, directly in front of the
electrical control. A non-instructed person is at risk of sustaining injuries
from electric shock.
Disconnect the main power supply and secure against unintentional
switch-on.
The electrical wiring diagram may only be removed by a qualified
electrician!
1 The electrical wiring diagram is located behind the rear cover (1).
2 The rating plate is located on the right-hand (ARROW) front side of the
machine.
