Visualisation
8. Visualisation
This chapter is intended for all personnel who operate, set up or maintain
the machine.
This chapter describes the individual menus as well as the options for set-
ting parameters in the visualisation.
This chapter covers the following:
General information about the display and accessing visualisation . . . 59
Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Menu bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Menu “Basic slice thickness” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Menu “Statistics” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Menü „Service“ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Menu “General”. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Additional information on the display . . . . . . . . . . . . . . . . . . . . . . . . . . 71
8.1 General information about the display and accessing visualisation
The display is used to show the menu pages. The Treif logo will first appear
on the display after switching on the machine.
A picture animation for opening and/or closing the infeed cover is shown on
the display as soon as the machine is ready for initialisation.
Initialising the machine
1. Open the infeed cover.
2. Ensure that nothing is in the cutting chute and the blade area.
3. Close the infeed cover.
The start screen is shown. An explanation of the display is provided in
the “Statistics” Page 66chapter.
