Preparation for complete cleaning
80 07/2019 244156V03_EN
9.3 Preparation for complete cleaning
Opening feeding lid
The feeding lid can be pushed open and closed when the machine is
switched on. It is guided in the lateral grooves of the casing.
1. Push (a) the infeed cover at the handle so far up that the lower guide
rollers engage in the upper end position.
- You now have access to the work area.
Folding the infeed cover
The lid can be folded to clean the rear side of the feeding lid.
1. Fold the upper end (b) of the infeed cover completely forward.
2. Ensure here that the lower guide rollers are down as far as possible in
the lateral guides (ARROW).
- You now have access to the inside of the feeding lid.
Opening the front door:
1. Pull the handle 1 to the outer side of the machine.
2. Swivel the unlocked front door 2 completely open.
1
2
AR1023 / 0
