Enkapsis & EnerSure Platform Installation Guide Rev07.2
Figure 10: CT Strip Mounting Screws
3.) Each CT strip requires an address to be designated.
a. For a standard 42 circuit panel (ANSI) the left CT strip (odd numbered
circuits) should be address position1 and the right CT Strip (even
numbered circuits) should be address position 3. (See CT Strip
Addressing Diagram)
