5700/5800 GPS Receiver User Guide 193
NMEA-0183 Output A
5700 and 5800
VTG Actual Track Made Good Over and Speed Over Ground
An example of the VTG message string is shown below. Table A.14
describes the message fields.
$GPVTG,,T,,M,0.00,N,0.00,K*4E
Table A.14 VTG message fields
Field Meaning
1 Track made good (degrees true)
2 T: track made good is relative to true north
3 Track made good (degrees magnetic)
4 M: track made good is relative to magnetic north
5 Speed, in knots
6 N: speed is measured in knots
7 Speed over ground in kilometers/hour (kph)
8 K: speed over ground is measured in kph
