Triple E COMMANDER Series - Video Cassette Recorder; Video Control Center

13-8
13.11 VIDEO CONTROL CENTER
Refer to manufacturer's manual for operating instruc-
tions and maintenance information. This unit is pow-
ered by inverter and 120 V AC.
13.10 VIDEO CASSETTE
RECORDER (OPTIONAL)
Refer to manufacturer's manual for operating instruc-
tions and maintenance information.
Fig. 13-10 VIDEO CONTROL CENTER
(COMMANDER ONLY)
COMMANDER / EMBASSY
Fig. 13-11 PHONE/CABLE
Commander
Embassy
13.12 PHONE AND CABLE TV
HOOK-UPS
The Commander phone and cable TV hook-ups are
located in the shoreline storage compartment. The
Embassy hook-ups are located on the exterior side-
wall.
To hook-up the cables raise the covers and connect
the terminals for the signals.
13.13 AC/DC VOLTAGE INVERTER
(OPTIONAL COMMANDER ONLY)
See the separate instruction manual in your
information packet labelled inverter.
13-8
