4.16 TV ANTENNA
Each motorhome is equipped with an extendable TV
antenna on top of the unit to provide reception at
remote locations. Always fully retract antenna when-
ever vehicle is moved or transported.
1. Extending and Retracting:
This crank controls the position of the antenna
assembly on top of the roof. Turn the crank
clockwise to raise the antenna and counterclock-
wise to lower. Always fully extend or retract
the antenna. Do not move or travel when the
antenna is extended. If parking where debris
can accumulate on roof, clean the antenna area
before retracting.
2. Rotation:
The antenna can be rotated to align with the
signal to provide the best reception. Grasp the
crank handle mounting plate on both sides and
pull down. Rotate the plate (antenna) until the
antenna is set to provide the best TV reception.
Always watch the reception on a TV to know
when the reception is the best. Always rotate
the antenna back to its storage position by
aligning the pointer on the plate to the reference
mark before lowering it.
Control
Fig. 4-30 TV ANTENNA SYSTEM
Antenna - Up
COMMANDER / EMBASSY
4.17 SATELITE DISH (optional)
The optional Satelite dish is located on top of the
unit to provide T.V. reception via Satelite signal. Al-
ways fully retract the Satelite dish whenever vehicle
is moved or transported.
1. Extending and Retracting:
This crank controls the position of the Satelite
receiver assembly on top of the roof. Turn the
crank clockwise to raise the Satelite dish and
counterclockwise to lower it. Do not move or
travel when the Satelite dish is raised. If parking
where debris can accumulate on roof, clean the
Satelite dish area before retracting.
2. Rotation:
The Satelite dish can be rotated to align with
the signal to provide the best reception. Always
rotate the Satelite dish back to its storage posi-
tion by aligning the pointer on the plate to the
reference mark before lowering it. Refer to the
manufacturer's manual for operating instruc-
tions and maintenance information.
Do not travel with the Antenna or Satelite Dish in
the "UP" position. This could cause major damage
to the roof, or roof top equipment.
WARNING
Satelite Dish - Up
Control
Fig. 4-31 SATELITE DISH SYSTEM
