Triple E COMMANDER Series - FRESH WATER TANK FILLING PROCEDURE; WATER PUMP OPERATION

12-2
12.1.1 FRESH WATER TANK
FILLING PROCEDUR
E
The water tank is not a pressure vessel. The lling
procedure is done via a water pressure system and
cannot be done without available water under
pressure. Make sure the vent/overow drain located
underneath the tank area is open, free and clear of
any obstruction before attempting to ll the tank. A
blocked vent during lling could cause serious damage
to the tank and even the underoor structures.
When lling fresh water tank:
1. Connect water hose to the city water inlet
connection.
2. Set the water pump switch to the o position.
3. Turn systems valve to “Tank Fill” position.
4. Turn on water supply.
5. Check the Monitor System inside the motorhome
for levels as the tank is lling. When the tank is
close to full, check for overow at the overow
drain. Turn the supply o as soon as water ows
from the drain.
6. Turn the systems valve back to normal, after
external supply is turned o.
7. Turn pump switch back to on and the system is
ready to be used.
COMMANDER / EMBASSY
Fig. 12-2 FRESH WATER TANK FILL (INLET)
CITY WATER HOOK-UP
Systems
Valve
Pump Switch
IMPORTANT
If you are starting from a dry system or
if some faucets have been open dur-
ing the tank lling procedure, you may
want to slowly open all faucets one at a
time to allow any trapped air to escape
from the system.
IMPORTANT
Never allow a full ow at the overow.
12.1.2 WATER PUMP
The water pump is designed to supply water from the
fresh water tank to the various areas of your mo-
torhome on demand. The main switch for the pump is
located on the Monitor Panel in the cabinet above the
entrance door. With the pump switch in the 'on' posi-
tion the pump comes on automatically and pressurizes
the various water lines when a faucet is opened.
Commander units have a remote switch on the Galley
and Vanity cabinet face as well as in the service mod-
ule. With the main switch in the 'on' position press the
remote switch once to switch the pump on and press it
again to turn it o.
The water pump has an inlet screen type lter mount-
ed to the body. If water ow in your unit deteriorates,
clean out this screen. (See pump owners manual for
details)
Commander
Embassy
