4.15.5 WATER SYSTEM (EMBASSY ONLY)
Fig. 4-26 EXTERIOR SHOWER
1. Exterior Shower (optional) (Fig 4-26):
a. Hot Water :
This water tap controls the ow of hot water
to the shower head. Turn clockwise to turn o
and counterclockwise to turn on.
b. Cold Water:
This standard water tap controls the ow of
cold water to the shower head. Turn clockwise
to turn o and counterclockwise to turn on.
c. Shower Head:
This standard exible hose shower system is
mounted on the front of the compartment.
Turn the handle and lift the head to use it.
Turn the collar on the head to temporarily shut
o the water spray.
Note: The Exterior Shower is equipped with
two shut o valves to shut o the hot and cold
water to the exterior shower for cold weather
use. See section 17 for Winterization proce-
dure.
2. Fresh Water Tank Fill
IMPORTANT
Use pressure regulator between
the outside water supply and the
motorhome to eliminate pressure
surges and spikes.
a
b
c
Fig. 4-28 WATER FILL SELECTOR
a
b
2
a. Water Fill Selector Valve:
This valve directs the ow of fresh water
into the water tank or directly into the water
system and bypass the tank. Turn counter-
clockwise when lling the tank and clockwise
to bypass the tank and plumb directly into the
water system.
b. Water Supply Hose Fitting:
This tting and cap is the water input tting.
Always install cover when water supply hose is
removed.
Fig. 4-2 EXTERIOR SHOWER
SHUT-OFF VALVES
