4.4.2 Setpoint 1 and Setpoint 2
Each input channel A to H has two Setpoint
On alarm states - Setpoint 1 (SP1) (General
alarm) and Setpoint 2 (SP2) (High alarm).
The available options are as follows:
• Activate
• Level
• Assign
To Access the Setpoint 1 or Setpoint 2
Setup Menu
From the Sentro eModule Setup Menu, use
the navigation keypad, scroll to
Setpoint 1 or Setpoint 2 and select OK.
If a Security Code has been enabled you will
be prompted to enter it, enter the Security
Code and select OK.
Activate
The Activate mode of Setpoint 1 and
Setpoint 2 can be setup to preference.
From the Setpoint 1 or Setpoint 2 Setup
Menu, use the navigation keypad, scroll to
Activate and select OK.
Use the navigation keypad, scroll to Over or
Under and select OK.
Use the navigation keypad, scroll to Set or
Quit and select OK.
