TX9165 User Manual
TX9165-UM-EN-07 95
8.3 Battery
The Sentro 8 battery back-up is equipped
with a sealed lead acid battery pack mounted
in an enclosure with a universal charger. The
lead acid battery is rated at 24 V and 2 Ah.
The universal charger will accept a supply
voltage of 85 to 265 V ac.
8.4 RS485 Repeater (TX2122.56)
An optional RS485 Repeater can be fitted to
boost the incoming data signal and increase
the transmission distance of the line.
8.5 Ethernet Converter
An optional Ethernet Converter can be fitted.
It is a single port RS485 to TCP/IP converter.
This enables the RS485 output of the Sentro
8 to be converted to a TCP/IP signal, with an
RJ45 connector for ease of connection.
Expected Battery Life
Equipment Battery life
Sentro 8 with battery back-up 12 hrs
Sentro 8 with battery back-up and RS485 Repeater 10 hrs
Sentro 8 with battery back-up and Ethernet Converter 8 hrs
www.trolex.com
