80 TX9165-UM-EN-07
4.6.4 And Function
A relay can be set to power-up only when
several Setpoint Commands are present at
the same time, so creating an And decision.
Voting Inputs
If Setpoint Commands are assigned to the
relay from for example, 4 assignors, set the
And function at 2. The relay will activate on a
vote of any 2 out of 4.
4.6.5 Text
Duty text can be entered to denote the input
duty or a tag reference of the input device.
www.trolex.com
