82 TX9165-UM-EN-07
5.2 Assign Fault
The Audio/Visual indicators are equipped
with self function monitoring and will
generate a Fault signal if a device failure is
detected.
The Fault signal will be generated at the
moment when the Audio/Visual alarm is
activated On.
The Fault state can be assigned to:
• Relay 1 output
• Relay 2 output
• Relay 3 output
• Relay 4 output
The screen prompts are as follows:
• Cursor
• Power-up the selected relay
