On Delay - Off Delay
The Activation On of the setpoint can be
delayed by an adjustable time period (t On).
The Activation Off of the setpoint can also
be delayed by an adjustable time period
(t Off).
4.5.3 Assign Fault
Each input channel E to H has a Fault alarm
output state.
• Analogue input signal over range
• Analogue input signal under range
• Module fault
To Access Assign Fault
From the Sentro rModule Setup Menu, use
the navigation keypad, scroll to Assign Fault
and select OK.
If a Security Code has been enabled you will
be prompted to enter it, enter the Security
Code and select OK.
Assign to
The Fault state can be assigned to the
following:
• Relay 1 output
• Relay 2 output
• Relay 3 output
• Relay 4 output
• The on-board audio/visual alarm
