3–22
Marshall Value/Voidless Density Pairs
To edit a density pair target, press 〈4〉 New Pair at the Target menu.
The gauge displays the Pairs menu:
The Pairs menu shows the three stored sets of Marshall and voidless
density value pairs and the New Pair and Disable options.
ENABLE A PAIR. To enable a displayed Marshall value/voidless
density pair, press the number key that corresponds to the desired
pair on the Pairs menu. The gauge enables the pair and returns to
the Target menu. Return to the Ready screen by pressing the
〈ESC〉
key.
STORE A NEW PAIR. To store a new target value, press 〈4〉 New
Pair at the Pairs menu. The gauge displays:
Use the number keys to enter the voidless density value. Press the
〈ENTER〉 key. The gauge displays:
Use the number keys to enter the Marshall value. Press the
〈ENTER〉 key.
1- V=xxxx MA=xxxx
2- V=xxxx MA=xxxx
3- V=xxxx MA=xxxx
4-New Pair 5-Disable
Voidless Density:
_ _ _ _ _ pcf
Press ENTER
Marshall Value:
_ _ _ _ _ pcf
Press ENTER
