Tyco Galaxy SC Controller User Manual

Tyco Electronics Galaxy SC Controller J85501F-1
4 - 20 Configuration Issue 13 February 2001
Converter
Management
Menu
This menu selection applies only to controllers used with serial interface
converters, presently limited to the +24V to -48V converters used in a
597-series converter carrier. These converters connect to the controller
through the rectifier communication bus wiring through the L-36
Rectifier Interface Module and L-23 BJC3 Rectifier Interface Board.
From the CONFIGURATION menu, select CONV MNGR to bring
up the CONVERTER MANAGEMENT menu. This allows you to
configure several converter parameters:
SET POINT: This setting controls the converter output voltage. Move
the cursor to this field and use the <+> or <-> keys to adjust the voltage
to the desired level. Press <ENTER> to save the change.
CONNECT VOLT: Converters can be configured to shut down when
the battery plant voltage drops in order to shed load and keep other more
critical loads operating longer during a prolonged battery discharge.
This CONNECT VOLT setting is the plant voltage at which the
converters will turn back on after having been shut down due to a low
voltage event. Move the cursor to this field and use the <+> or <-> key
to adjust the voltage to the desired level. Press <ENTER> to save the
change.
DISCON VOLT: This setting controls the voltage at which the
converters will shut down due to a low voltage event when this feature
is enabled via the LOW V DISCON field below. Move the cursor to this
field and use the <+> or <-> key to adjust the voltage to the desired level.
Press <ENTER> to save the change.
LOW V DISCON: This field enables or disables the converter shut
down option at low battery plant voltage. Move the cursor to this field
and use the <+> or <-> key to set the field value to EN or DIS. Press
<ENTER> to save the change.
REMOVE CONV: May be used to remove a converter from the
configuration. The converter number is selected using <+> and <-> keys
CONVERTER MANAGEMENT
SET POINT : 50.00
CONNECT VOLT: 25.00
DISCON VOLT : 23.00
LOW V DISCON: DIS
REMOVE CONV: __
ADJ PL VOLT : 50.00 RST PL VOLT
