The four possible values are: RD(HW), RD(HW,SW), RD(SW),
RD_WR. The first three values are read-only permission, which means
users can login through the modem and retrieve information. The fourth
value (RD_WR) allow users who login through the modem to change
the system configuration (Super-user or Administrator privileges).
Again, this field has a hardware switch (switch 4 of DIP switch SW203
on the BJH board) and a software switch associated with it. To set the
field value to RD_WR, the hardware switch must be set to ON (1
position) and software switch must be enabled; all other positions of the
switches will disable the write privilege.
Set the Read/Write permission for Remote port (AUX1): This field
lets you set the Read/Write permission for the remote (auxiliary) port. It
works the same way as the modem port; the hardware switch is switch
5 of SW203 on the BJH board.
Set the Read/Write permission for Local port (LOC RW): This field
lets you set the Read/Write permission for the local port. It works the
same way as the modem port; the hardware switch is switch 6 of SW203
on the BJH board.
Low Voltage
Disconnect Menu
From the CONFIGURATION menu select LVD to bring up the LOW
VOLTAGE DISCONNECT menu. This menu allows you to configure
the various parameters for two optional low voltage disconnect
contactors.
Up to 3 optional LVD devices can be connected to a Galaxy SC and
configured from this screen. For plants without any BIC card located on
a GPS serial rectifier bay, LVD control is obtained via wiring off the
UR1 (Contactor 1), UR2 (Contactor 2), or VLV/UR3 (Contactor 3)
relays on TB2/3 of the BJT card on the rear of Galaxy SC. These relays
cannot be configured for use as alarm relays if used for LVD contactor
control. A "URC" User Relay Conflict alarm will activate if contactor
programming from this screen is attempted for a user relay that already
has an alarm assigned to it or vice versa.
As soon as any BIC card is connected to a serial rectifier bus, the user
relays are released from their use for LVD contactor control and this
LOW VOLTAGE DISCONNECT
CONTACTOR 1..
CONTACTOR 2..
CONTACTOR 3..
