Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Configuration 4 - 41
function is transferred to the LVD control circuits of all BIC cards in the
plant. Please note that in a standard GPS configuration using BIC cards,
Contactor 1 is wired to and controls all BATTERY contactors in the
plant, while Contactor 2 and Contactor 3 are wired to and control only
LOAD contactors.
Select the LVD contactor to be configured and press <ENTER>. The
configuration screen for that contactor appears as follows:
STATE: This field indicates the present state of the selected contactor.
It is a read-only field.
TYPE: This setting identifies the type of contactor, BAT, LOAD or
NONE that has been installed in the plant. If there are battery or load
contactors in your system, you must identify the type. Please be sure
that the wiring for the contactor being configured matches the type
chosen here. For standard GPS configurations using BIC cards,
Contactor 1 is wired to and controls all BATTERY contactors in the
plant, while Contactor 2 and Contactor 3 are wired to and control only
LOAD contactors. To toggle between the various contactor types, move
the cursor to this field and use the <+> or <-> key to select the desired
type. Press <ENTER> to save the change.
CONNEC VOLT: This setting configures the plant voltage at which
the contactor will reconnect to the bus. To prevent the contactor from
re-operating when battery voltage increases due to load removal, a
voltage several volts higher than the disconnect voltage is
recommended. Use the <+> or <-> key to adjust the voltage to the
desired level. Press <ENTER> to save the change.
DISCON VOLT: This setting configures the plant voltage at which the
contactor will disconnect from the bus. Use the <+> or <-> key to adjust
the voltage to the desired level. Press <ENTER> to save the change.
CONTACTOR 1
STATE: NONE
TYPE: NONE
CONNEC VOLT: 48.00
DISCON VOLT: 44.00
