Tyco Electronics Galaxy SC Controller J85501F-1
4 - 42 Configuration Issue 13 February 2001
Converter
Management
Menu
This menu selection applies only to controllers used with serial interface
converters, presently limited to the +24V to -48V converters used in a
597-series converter carrier. These converters connect to the controller
through the rectifier communication bus wiring through the L-36
Rectifier Interface Module and L-23, BJC3 Rectifier Interface Board.
From the CONFIGURATION menu select CONV MNGR to bring up
the CONVERTER MANAGEMENT menu. This menu allows you to
configure several converter parameters discussed below.
Right side, bottom line only (across from ADJ PL VOLT): RST PL
VOLT
SET POINT: This setting controls the converter output voltage. Move
the cursor to this field and use the <+> or <-> key to adjust the voltage
to the desired level. Press <ENTER> to save the change.
CONNEC VOLT: Converters can be configured to shut down when the
battery plant voltage drops in order to shed load and keep other more
critical loads operating longer during a prolonged battery discharge.
This CONNEC VOLT setting is the plant voltage at which the
converters will turn back on after having been shut down due to a low
voltage event. Move the cursor to this field and use the <+> or <-> key
to adjust the voltage to the desired level. Press <ENTER> to save the
change.
DISCON VOLT: This setting controls the voltage at which the
converters will shut down due to a low voltage event when this feature
is enabled via the LOW V DISCON field below. Move the cursor to this
field and use the <+> or <-> key to adjust the voltage to the desired level.
Press <ENTER> to save the change.
LOW V DISCON: This field enables or disables the converter shut
down option at low battery plant voltage. Move the cursor to this field
and use the <+> or <-> key to set the field value to EN or DIS. Press
<ENTER> to save the change.
CONVERTER MANAGEMENT
SET POINT: 50.00
CONNEC VOLT: 25.00
DISCON VOLT: 23.00
RMOVE CONV: _
ADJ PL VOLT: 50.00: RST PL VOLT
