Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Operation 6 - 9
Selecting UDO displays the values of any user-defined objects that have
been optionally added to the system.
Select the CONVERTER field to display the type, state, load and
capacity of all converters in the system, in addition to the total converter
drain (SUMMARY) and capacity.
Selecting BAY INTFC allows a display of the voltage, current, and
temperature channels of any of the BIC cards presently recognized by
the system.
Selecting AC DISTRIBUTION displays the values of ac phase voltages
and currents that may have been optionally linked to Remote Peripheral
Monitor channels.
Select DISTRIBUTION DC to display the state of a distribution fuse
alarm that may have been optionally linked to a Remote Peripheral
Monitor channel.
Selecting MEAS CHAN displays the VIEW CHANNEL STATUS
menu shown below. Selecting any of the fields will display the values
of Remote Peripheral Monitor channels that have optionally been added
to the system.
Selecting any of the fields displays the values of Remote Peripheral
Monitor channels that have optionally been added to the system.
VIEW CHANNEL STATUS
VOLT CHAN
SHUNT CHAN
TEMP CHAN
RELAY CHAN
BIN CHAN
DERV CHAN
