43
-
No.
Item
Setting range
Edit unit
Remarks
S061
ACT timing adjustment at the start of 2
nd
bar-tacking
This item adjusts needle thread tension output start timing
at 2
nd
bar-tacking section.
-5 ~ 5
1 stitch
*2
S062
Number of stitches for bar-tacking at the start of
sewing
This item sets number of stitches of bar-tacking at the
start of sewing.
0 ~ 8
1 stitch
-
S063
Sewing pitch for bar-tacking at the start of sewing
This item sets sewing pitch of bar-tacking at the start of
sewing.
0.00 ~ 0.70
0.05 mm
*2
S064
Bar-tacking width at the start of sewing
This item sets bar-tacking width at the start of sewing.
0.0 ~ 3.0
0.1 mm
-
S065
Lengthwise compensation of bar-tacking at the start
of sewing
This item sets start position of bar-tacking in lengthwise
direction at the start of sewing.
0.0 ~ 5.0
0.1 mm
*2
S066
Crosswise compensation of bar-tacking at the start of
sewing
This item sets start position of bar-tacking in crosswise
direction at the start of sewing.
0.0 ~ 2.0
0.1 mm
*2
S067
Bar-tacking width at the end of sewing
This item sets tie stitching width at the end of sewing.
0.1 ~ 1.5
0.1 mm
-
S068
Number of stitches of bar-tacking at the end of sewing
This item sets number of stitches of bar-tacking at the end
of sewing.
0 ~ 8
1
-
S069
Lengthwise compensation of bar-tacking at the end of
sewing
This item sets start position of bar-tacking in lengthwise
direction at the end of sewing.
0.0 ~ 5.0
0.1 mm
*2
S070
Crosswise compensation of bar-tacking at the end of
sewing
This item sets start position of bar-tacking in crosswise
direction at the end of sewing.
0.0 ~ 2.0
0.1 mm
*2
S081
Knife motion
This item sets “with/without motion" of normal cloth cutting knife.
-
-
-
S083
Knife motion at 1
st
cycle of double stitching
This item sets “with/without motion" of cloth cutting knife at 1
st
cycle
when double stitching is performed.
-
-
*2, *3
*1: Displayed according to the shape.
*2: Displayed when it is set to with edit. Refer to “V-12. Method of setting sewing data with/without edit” p.32.
*3: Displayed when the function is selected.
Normal knife
motion OFF
Normal knife
motion ON
Normal knife
motion OFF
Normal knife
motion ON
