77
-
Presser size error (Width direction: right and
left)
When stitching data exceeds the size of both right
and left of width direction of presser.
(During individual sewing/cycle
sewing)
Sewing data edit screen
[S005]Left overedging width
(during continuous sewing)
Standard screen
Presser size error (length direction: rear)
When stitching data exceeds the size of rear of
length direction of presser.
(During individual sewing/cycle
sewing)
Sewing data edit screen
[S002] Cloth cutting length
(during continuous sewing)
Standard screen
Panel is connected to the machine other than
supposed (machine type error)
When machine type code of system is improper in
case of initial communication.
Wrong system version
When version of system software is improper in
case of initial communication.
Main shaft motor encoder defectiveness or
phase-lack
When encoder of sewing machine motor is
abnormal.
Main motor hole sensor defectiveness or
position sensor defectiveness
When hole sensor or position sensor of sewing
machine motor is defective.
Reverse rotation of main shaft motor
When sewing machine motor rotates in reverse
direction.
Phase-lack of power
When phase-lack of input power occurs.
Momentary power failure detected
When input power is instantaneously OFF.
Over voltage
When input power source voltage is equal to or
more than the specified value.
Under voltage
When input power source voltage is less than the
specified value.
Abnormality of main shaft motor IPM
When IPM of servo control PCB is abnormal.
Overcurrent of main shaft motor
When current flows excessively to sewing
machine motor.
Abnormality of stepping motor power
When the stepping motor power of the
servo-control PCB is out of the range of the
specified values.
