UNI-T UTD1000L Series User Manual

Chapter 2 UTD1000L Series Oscilloscope Overview
2.1 UTD1000L Series Oscilloscope Introduction
UTD1000L Handheld Digital Storage Oscilloscope (Hereinafter referred to as “The Oscilloscope”)
combines digital scope and multimeter functions just into one tool. The ease-of-use feature, excellent
technical indicators and multi-functions offered the Oscilloscope can get your work done much faster.
The series offers four models for your option:
Model
Bandwidth
Sample Rate
Channels
UTD1025CL
25MHz
200MS/s
Single Channel
UTD1050CL
50MHz
200MS/s
Single Channel
UTD1025DL
25MHz
250MS/s
Dual Channel
UTD1050DL
50MHz
250MS/s
Dual Channel
UTD1000L Series Oscilloscopes offer users a simple and clear front panel that helps to perform primary
operations, a design you often get used to and can save you a great amount of time to learn about the
Oscilloscope. In order to speed up calibrations and measurements, pressing AUTO button can make the
oscilloscope display proper waveforms and settings directly. Meanwhile the Oscilloscope offers SHIFT
button to combine with other buttons to further operate the menus much easier. Beside ease of use, this
series outstands itself with superb performance and powerful functions, such as remarkable trigger and
analysis ability, making it easy to capture and analyze the waveforms; high-definition Display and math
function, ensuring a very clear and fast view on waveforms and finding out the signal problem.
2.2 UTD1000L Series Oscilloscope Accessories
Unpack the carton and you will see following accessories should be included:
No.
Description
Standar
d
1
UNI-T Oscilloscope
●
2
Power Adaptor, 1 pc
●
3
UTD1000CL Standard Probe, 1pc; UTD1000DL Standard Probe, 2 pcs
●
4
Multimeter Test Leads, 2pcs (one red, one black)
●
5
UTD1000DL standard UT-M04 (4A current divider module), 1pc;
UT-M10 (mA current module), 1pc.
UTD1000CL standard UT-M07 (10A current divider module),1pc
●
6
Oscilloscope probe adjusting tool, 1pc
●
7
USB wire, 1pc
●
8
Operating Manual, 1pc
●
9
CD (for communication software between PC and the Oscilloscope),
1pc
●
10
carrying bag, 1pc
●
2.3 UTD1000L Series Oscilloscope Key Features
2.3.1 Scope
● Totally Auto Scale; Vertical Scale and Timebase automatically adjusted with the signal and without any
manual interference;
●Unique and powerful Auto Setup, quick and accurate to set up for signals with any DC component;
● Wider voltage measuring range; Coupled with 10×probe with attenuation up to 200V/div;
8 UTD1000L User Manual
