UNI-T UTD1000L Series User Manual

6.13 Autoset
Autoset is used to simplify the operations. Press AUTObutton and then the Oscilloscope will automatically
adjust vertical factor and timebase range based on the waveform amplitude and frequency until the
waveform displays steadily on the screen. System settings for Autoset function are shown in the following
table:
Table 6-22
Functions
Settings
Acquire Mode
Normal Sample
Display Type
YT
SEC/DIV
Adjust based on signal frequency
VOLT/DIV
Adjust based on signal amplitude
Trigger Type
Edge
Trigger Level
central point of signal
Trigger
Coupling
DC
Trigger Slope
Rise
Trigger Mode
Auto
UTD1000L User Manual 71
