Figure 5-22 Measuring Capacitanc in Relative Mode
5.7 Selecting Manual/Auto Ranging
The multimeter defaults at auto mode. To access manual ranging, operate as follows:
1. Press V or R button, and measure mode option is AUTO.
2. Press F2 to select manual measure mode, then the ranging mode will change into
Manual status accordingly.
3. Under manual ranging mode, keep pressing F3 button to reach up to the highest range,
after that, then the selected range jumps directly to the lowest range and circulates again.
The currently selected range shows just above measuring readings.
4. Press F2 button, Auto icon shows on left upper display, indicating the multimeter has returned to full
autoset mode.
Figure 5-23 Manual Ranging
42 UTD1000L User Manual
