Chapter 5 Using the Multimeter
5.1 About the Chapter
This chapter introduces the multimeter functions built in the Oscilloscope; examples are also offered to
illustrate how to use the menus and the basic measurements. To switch from Oscilloscope mode to
Multimeter mode, press DMM/DSO button to access DMM mode, the display screen will change into
multimeter interface accordingly.
5.2 Connections to the Multimeter
UTD1000L has two multimeter input terminals: COM, V/Ω, matched to 4-mm banana plugs of test leads.
UTD1000DL: One UT-M04 (4A current divider) and one UT-M10 (mA current module) are also offered to
use in the measurements
UTD1000CL: One UT-M07 (6A current divider) is also offered to use in the measurements
5.3 Display Indicators
Description:
1. Battery Indicator
2. AUTO Autoset indicator
3. Indicators for Measurement Types:
DC Voltage Measurement
AC Voltage Measurement
DC Current Measurement
UTD1000L User Manual 29
