UNI-T UTD1000L Series User Manual


Figure 6-22 Waveform Record Menu
Set up as the following table:
Table 6-11 Record Menu
Menu
Setting
s
Description
Wave
Record
Record
To turn on/off waveform record
function.
Play
----
To play recorded waveform
Stop
----
To stop recording or playing waveforms
Record
----
To begin the recording.
Figure 6-23 Save Menu for Recorded Waveforms
Table 6-12 Save Menu for Recorded Waveforms
Menu
Settings
Description
Wave Record
Save
To turn on /off waveform storage function
60 UTD1000L User Manual
