UNI-T UTD1000L Series User Manual

Display Color
Color/Black&White
Waveform Display Zone
Horizontal: 12div, 25dot/div; Vertical: 8div, 25dot/div;
Backlight Brightness
Adjustable
Backlight Intensity
300nit
Language
Multilingual
Interface
Standard
USB cable, 1 pc
UTD1000DL: UT-M04(4A current divider module), 1pc,
UT-M10(mA current module), 1pc;
UTD1000CL: UT-M07(10A current divider module), 1pc.
Optional
----
Power Adaptor:
Mains Voltage
100~220 V AC rms,45~440Hz
Output Voltage
9VDC
Output Voltage
4A
Battery: 7.4 V, 3600mA rechargeable lithium batter; UTD1000CL: 8-hour battery life UTD1000DL: 6-hour
battery life;
Environment
Temperature
Operating:0℃～+40℃
Non-Operating:-20℃～+60℃
Cooling Method
Naturally cooled down
Humidity
＋10℃～＋30℃:≤90%±5%RH，
＋30℃～＋40℃:≤60%±5%RH
Altitude
Operating:3,000m
Naturally cooled down 5,000m
Mechanical Specifications
Dimensions
(Reference Data)
199mm × 118mm × 49mm
Weight
( Net Weight)
Packing not included
0.9kg
Packing Included
2.3kg
IP Degree
IP2X
Calibration Period
one time for each year
Appendix B Maintenance
1. General Service
Do not store or place the Oscilloscope in places that may get its LCD exposed to direct sunshine for a
long time. Do not let spray agent, liquid and solvent stick onto the Oscilloscope or probe so as to avoid any
damage to the Oscilloscope or probe
Cleaning
Check the Oscilloscope and its probe as actual operation requires. Clean the Oscilloscope surface as
follows:
80 UTD1000L User Manual
