92
SIDE SHIFT (OPTION) (cont’d)
OPERATION OF THE CONTROL LEvER FOR THE SIDE SHIFT
A forklift attached with a
side shift has a control
lever to operate the side
shift, in addition to the
control levers for standard
operations.
GENERAL CARE AND MAINTENANCE
When you pull the lever toward
the operator, the shift nger
bar (with forks mounted) shifts
(moves) to the right.
When you push the lever
forward, the shift nger bar (with
forks mounted) shifts (moves) to
the left.
CAUTION
!
• Do not move the levers suddenly and quickly. There is a risk
of a load collapse.
NOTE:
The shifting speed changes depending on the amount the lever is
moved forward or backward.
WARNING
!
!
• When you operate your side shift, make sure to raise the
forks approximately 100 - 200 mm (3.94 - 7.87 in) from the
ground before operation. If you shift with the forks while they
are in contact with the ground, the side shift forks or load
could get caught and damage the forklift or load.
