UniPOS IFS7002 two signal loops
Instruction Manual Page 29
Revision 11/01.17 Of 145
If faults are detected, the following
screen appears:
Each message can be displayed
in a few lines from 1 to 4. It brings
out the following information
Text for the type of the fault
this information is mandatory;
Information for the device
(zone if the device is fire
detector, loop and address)
in case the fault condition is
in an addressable device;
Text message for the zone
visualized if the fault
condition is in an addressable
fire detector;
Text message for the device
visualized if the fault condition is in an addressable device.
Buttons and situated in the right panel section scroll the pages up and down next page
or previous page (if any are available). One page contains two messages for fault condition.
12.2.2. Menu Disables
The menu displays detailed information for disabled zones, disabled addressable devices and
monitored outputs of the fire control panel.
Menu Disables contains the following subordinate menus and screens:
Screen Total displays information for all disables;
Menu Zones displays information only for disabled zones;
Menu Devices displays information only for disabled addressable fire detectors;
Menu Outputs display information only for disabled outputs (monitored outputs and
addressable output devices).
12.2.2.1. Screen Total
If no disables are set, the
following screen appears:
Mode:DAY LOC ActInp 0000 11:44:29 Thu 11 Feb 2010
FIRE CONTROL PANEL IFS7002
UniPOS
Faults Total: 00003/00001*
Disables Total: 000
Failed Outputs: 00000
Disabled Outputs: 000
List/Faults/Total
0003
0001 Fault in Zone 003
Zone: Zone 003
0002 Removed Device
Zone003 Loop001 Addr003
Zone: Zone 003
Addr: Point 1.003
Fau
Mode:DAY LOC ActInp 0000 11:45:23 Thu 11 Feb 2010
FIRE CONTROL PANEL IFS7002
UniPOS
List/Disables/Total
NO DISABLES
