UniPOS IFS7002 two signal loops
Instruction Manual Page 39
Revision 11/01.17 Of 145
When you press button
when the Go to field is empty, a
menu with a group of parameters of
the selected zone will appear on the
display:
Screen Devices;
Menu Fire Phase 1 Outputs;
Menu Fire Phase 2 Outputs;
Screen Zone parameters.
The arrow >> points at the
selected group of parameters.
Buttons and allow the
user to select the next or the
previous group of parameters (if any
are available).
12.2.9.1. Screen Devices
It displays a list of fire detectors
integrated in the zone:
The loop where each device is
integrated, as well as its address is
displayed on a list. The list is
visualized in the form of pages; each
page contains information for a
maximum of 15 devices. Buttons
and in the right panel section
appear where more than one page is
available; they allow the user to
switch between the next and
previous page (if available).
12.2.9.2. Menus Fire Phase 1 Outputs and Fire Phase 2 Outputs
The menus allow the user to
display information for outputs,
associated to the zone, which will
respond at Fire Condition (phase Fire
condition stage I or phase Fire
condition stage II). The menus
contain:
Screen Panel Outputs;
Screen List of addressable
outputs.
Mode:DAY LOC АctInp 0000 18:49:16 Fri 12 Mar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
>> Devices
Fire Phase 1 Outputs
Fire Phase 2 Outputs
Zone parameters
Mode:DAY LOC АctInp 0000 10:59:33 Sat 13 Мar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
Parameters: Zone 1 List of Devices Total: 21
Loop1 Addr1 Loop1 Аddr11 Loop2 Аddr12
Loop1 Аddr2 Loop2 Аddr1 Loop2 Аddr13
Loop1 Аddr3 Loop2 Аddr2 Loop2 Аddr14
Loop1 Аddr4 Loop2 Аddr6 Loop2 Аddr16
Loop1 Аddr10 Loop2 Аddr7 Loop2 Аddr114
Mode:DAY LOC АctInp 0000 11:24:37 Sat 13 Mar 2010
FIRE CONTROL PANEL IFS7002
UniPOS
Parameters: Zone 1 Fire Phase 1 Outputs
>> Panel Outputs
List of addressable Outputs
