UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 79
Revision 11/01.17 Of 145
13.5.1. Menu Devices
The menu allows the user to integrate (to include) a device in a zone and to exclude a device
from a zone. It contains the following submenus and screens:
 Screen List of devices;
 Screen Set zone as free;
 Menu Remove address;
 Menu Remove address range;
 Menu Add address;
 Menu Add address range.
If no devices are present in the zone (free zone) screen Set zone as free, menu Remove address,
and menu Remove address range are not accessible. If 60 devices are already added to the zone
(the zone is full), the menu Add address and menu Add address range are not accessible.
13.5.1.1. Screen List of devices
The screen displays a list of fire
detectors included in the zone. For
each devices is displayed the loop
where it is included and the device
address in the loop:
If no fire detectors are integrated in the zone, a screen with the text message Free zone appears.
13.5.1.2. Screen Set zone as free
The command screen Set zone
as free allows the user to remove all
devices from the zone.
Press button to remove
the devices from the zone and to exit
the screen.
Mode: DAY LOC 13:19:31 Mon 22 Mar 2010
SetUp Zone 1 List of devices Total: 17
Lp1 Аddr1 Lp2 Аddr110
Lp1 Аddr2 Lp2 Аddr114
Lp1 Аddr3
Lp1 Аddr4
Lp1 Аddr10
Lp1 Аddr11
Lp2 Аddr1
Lp2 Аddr2
Lp2 Аddr6
Lp2 Аddr7
Lp2 Аddr12
Lp2 Аddr13
Lp2 Аddr14
Lp2 Аddr16
Lp2 Аddr17
Mode: DAY LOC 13:28:25 Mon 22 Mar 2010
SetUp Zone 1 Set Zone as free
Warning!
All addresses will be removed from the Zone!
– confirm
– cancel
