Uponor Smatrix Base PULSE User Manual

CD0000100
Figure 3. Program P1
CD0000101
Figure 4. Program P2
CD0000102
Figure 5. Program P3
CD0000103
Figure 6. Program P4
CD0000104
Figure 7. Program P5
CD0000105
Figure 8. Program P6
Select scheduling program
To select a scheduling program:
1. Press OK to enter parameter edit mode.
2. Use buttons - or + to select program.
Select between: P1–P6, U (user defined program) and Off.
3. Press OK to confirm program selection and return to the settings
menu.
Customise user defined program for a single day
To customise the user defined program:
1. Press OK to enter parameter edit mode.
2. Use buttons - or + to select program U.
3. Press OK to confirm program selection and return to the settings
menu.
The current day starts flashing.
4. Use buttons - or + to select a day.
5. Press and hold OK until 00:00 appears on the display (takes
about 2 seconds).
6. Press OK to switch the marked interval between Comfort (
)
and ECO mode ( ).
7. Use buttons - or + to move the marker (at the bottom of the
display). When moving the marker from one interval to another
save the selected mode to that interval.
8. Repeat steps 6 and 7 until the display shows 23:30.
9. Press + to finalize the current day and the software exits to the
settings menu.
10. Repeat from step 1 to customise another day.
78
|
Uponor Smatrix Base PULSE
|
Installation and operation manual
