8-46
System Menu > Default Setting on the Machine (System Menu)
Proxy
Optional Network
Basic
* The setting will be changed after restarting the device or network.
Item Description
Proxy Set the proxy for connection to the Internet from an application.
Value: Off, On
Use the Same Proxy
Server for All Protocols
Set whether the same proxy server is used for all protocols. To use the same proxy server,
select the [Use the Same Proxy Server for All Protocols] checkbox.
Proxy Server (HTTP) Set a proxy server (HTTP).
Value: (Enter the proxy address and port number.)
Proxy Server (HTTPS) Set a proxy server (HTTPS). This setup is available when "Use the Same Proxy Server for All
Protocols" is [Off].
Value: (Enter the proxy address and port number.)
Do Not Use Proxy for
Following Domains
Set domains for which no proxy is used.
Value: (Enter the domain name.)
System/Network Optional Network
This function is displayed when the optional Network Interface Kit is installed.
Item Description
Host Name Check the host name of the machine. Host name can be changed from Embedded Web Server
RX.
Changing Device Information (page 2-42)
TCP/IP Setting For details on setting value, refer to TCP/IP Setting on page 8-42.
NetWare Use NetWare to receive documents.
See the Operation Guide for the optional network interface card for details.
Value: Off, On
AppleTalk Selects whether to receive documents using AppleTalk.
*
Value: Off, On
LAN Interface Select the LAN Interface type.
*
Value:
Auto, 10BASE-T Half, 10BASE-T Full, 100BASE-T Half, 100BASE-T Full, 1000BASE-T
This function is displayed when the optional Network Interface Kit is installed.
MAC Address Filter Select whether to use MAC Address Filter.
See the Operation Guide for the optional network interface card for details.
Value: Off, On
Restart Network Restarts the network card of the device.
To Next Page
