Installing and Setting up the Machine > Part Names

Part Names

Machine Exterior

Optional Equipment (page 11-2)

1 Document Processor (Option)

2 Original Loaded Indicator

3 Original Width Guides

4 Cleaning Cloth Compartment

5 Original Table

6 Original eject table

7 Original stopper

8 USB Port (A1)

9 Slit Glass

10 Original Size Indicator Plates

11 Platen

12 Operation Panel

13 Front Cover

14 Cassette 1

15 Cassette 2

16 Handles

17 Right Cover 2 Handle

18 Right Cover 2

19 Main Power Switch

20 Inner Tray

3 8 11 12

14 15 16 19 20 16

45 6 9 107

17 18
