xv
> About the Operation Guide (this Guide)
Originals and Paper Sizes
Original sizes and paper sizes such as A4, B5, and Letter can be used in both the horizontal and vertical orientations. To
distinguish the orientations when these sizes are used, "R" is added to sizes used in the horizontal orientation.
Icons on the touch panel
The following icons are used to indicate original and paper placement orientations on the touch panel.
Orientation Indicated size
*
* Original/paper sizes that can be used vary depending on the function and source tray. For details,
refer to Specifications
on page 11-23.
Vertical
orientation
Dimension Y of the original/paper is longer than X.
A4, B5, A5, B6, A6
Letter, Statement
Horizontal
orientation (-R)
Dimension Y of the original is shorter than X.
A4-R, B5-R, A5-R, B6-
R, A6-R, Letter-R,
Statement-R
Orientation Original Paper
Vertical
orientation
Horizontal
direction
