4-7
Printing from PC > Banner printing
Banner printing
When a document length from 470.1 mm (18.51") to a maximum of 1220.0 mm (48") is specified for printing, the print job
is treated as banner printing.
* When the banner tray (option) is used, up to 10 sheets of banner paper can be fed continuously. (Refer to Using the
Banner Tray (Option) on page 4-10.)
Follow the steps below to set banner paper in the printer driver.
1
Display the screen for registering the original size.
1 Click the [Basic] tab.
2 Select [Custom] in the "Print size" menu.
2
Register the original size.
1 Click the [New] button.
2 Enter the name, length (470.1 mm (18.51") or longer), and width of the custom paper size
being registered.
3 Click the [OK] button.
Max. number of sheets 1 sheet (manual feed), 10 sheets (when optional banner tray is attached*)
Paper width 210 to 304.8 mm (8.26" to 12")
Paper length Max. 1220 mm (48")
Paper weight 136 to 163 g/m
2
Media type Heavy 2
To Next Page
