NOTE!
The currents in given ambient temperatures (in chapter 8.2 Vacon® 100 - technical
data) are achieved only when the switching frequency is equal to or less than the
factory default.
If your process includes a cyclical load, for example if there are lifts or winches, speak to the
manufacturer to get the dimensioning information.
8.1.3 MAINS VOLTAGE 525-600 V
Table 36: The power ratings of Vacon
®
100 in mains voltage 525-600 V, 50-60 Hz, 3~
Frame Drive
type
Loadability Motor shaft
power
Low High Max
current
I
s
2s
600 V
Continu
ous
current
I
L
[A]
Input
current
I
in
[A]
10%
over-
load
current
[A]
Continu
ous
current
I
H
[A]
Input
current
I
in
[A]
50%
over-
load
current
[A]
10%
over-
load
40◦C
[Hp]
50%
over-
load
50◦C
[Hp]
MR5 0004 3.9 4.6 4.3 2.7 3.2 4.1 5.4 3.0 2.0
0006 6.1 6.8 6.7 3.9 4.5 5.9 7.8 5.0 3.0
0009 9.0 9.0 9.9 6.1 6.7 9.2 12.2 7.5 5.0
0011 11.0 10.5 12.1 9.0 8.9 13.5 18.0 10.0 7.5
MR6 0018 18.0 19.9 19.8 13.5 15.2 20.3 27.0 15.0 10.0
0022 22.0 23.3 24.2 18.0 19.8 27.0 36.0 20.0 15.0
0027 27.0 27.2 29.7 22.0 23.1 33.0 44.0 25.0 20.0
0034 34.0 32.8 37.4 27.0 27.0 40.5 54.0 30.0 25.0
MR7 0041 41.0 45.3 45.1 34.0 38.4 51.0 68.0 40.0 30.0
0052 52.0 53.8 57.2 41.0 44.9 61.5 82.0 50.0 40.0
0062 62.0 62.2 68.2 52.0 53.2 78.0 104.0 60.0 50.0
MR8 0080 80.0 90.0 88.0 62.0 72.0 93.0 124.0 75.0 60.0
0100 100.0 106.0 110.0 80.0 89.0 120.0 160.0 100.0 75.0
0125 125.0 127.0 137.5 100.0 104.0 150.0 200.0 125.0 100.0
MR9 0144 144.0 156.0 158.4 125.0 140.0 187.5 250.0 150.0 125.0
0208 208.0 212.0 228.8 170.0 177.0 255.0 340.0 200.0 150.0
TECHNICAL DATA, VACON® 100 VACON · 121
