Vacon 100 - Wall Mounting of MR6, North America

4.3.3 WALL MOUNTING OF MR6, NORTH AMERICA
7.68
5.83
Ø0.61
Ø0.35
21.93 21.30
Ø0.35
5.83
9.02
5.83
5.94
UL Type 1
UL Type 12
1.65 1.72
5.83
5.94
Ø1.57 Ø1.30 Ø1.57
Ø0.98
Fig. 12: The dimensions of the AC drive, MR6 [in]
