3.2 TYPE DESIGNATION CODE
The type designation code of Vacon is made of standard codes and optional codes. Each part
of the type designation code agrees to the data in your order. The code can have this format,
for example:
VACON0100-3L-0061-5+IP54
VACON0100-3L-0061-5-FLOW
Table 3: The description of the parts in the type designation code
Code Description
VACON This part is same for all the products.
0100 The product range: 0100 = Vacon 100
3L Input/Function: 3L = A 3-phase input
0061 The drive rating in amperes. For example, 0061 = 61 A
5 The mains voltage:
2 = 208-240 V
5 = 380-500 V
6 = 525-600 V
7 = 525-690 V
FLOW The Vacon 100 FLOW AC drive
+IP54 The optional codes. There are many options, for example +IP54 (an AC drive with
the IP protection class IP54)
3.3 CONTENTS OF THE DELIVERY
The contents of the delivery, MR4-MR9
•
The wall-mounted drive with an integrated control unit
•
An accessories bag
•
Quick Guide, Safety Instructions, and the manuals for the options that you ordered
•
Installation Manual and Application Manual if you ordered them
3.4 REMOVING THE PACKAGING AND LIFTING THE AC DRIVE
3.4.1 WEIGHT OF THE AC DRIVE
The weights of AC drives of different frames are very different. It can be necessary for you to
use a lifting device to move the drive from its package.
VACON · 16 RECEIVING THE DELIVERY
