Vacon 100 Installation Manual

10 TECHNICAL DATA, VACON® 100 HVAC
10.1 AC DRIVE POWER RATINGS
10.1.1 MAINS VOLTAGE 208-240 V
Table 50: The power ratings of Vacon
®
100 HVAC in mains voltage 208-240 V, 50-60 Hz, 3~
Frame Drive type Loadability Motor shaft power
Low* 230 V mains 208-240 V
mains
Continuous
current I
L
[A]
Input current
I
in
[A]
10% overload
current [A]
10% overload
40°C [kW]
10% overload
40°C [Hp]
MR4 0003 3.7 3.2 4.1 0.55 0.75
0004 4.8 4.2 5.3 0.75 1.0
0006 6.6 6.0 7.3 1.1 1.5
0008 8.0 7.2 8.8 1.5 2.0
0011 11.0 9.7 12.1 2.2 3.0
0012 12.5 10.9 13.8 3.0 4.0
MR5 0018 18.0 16.1 19.8 4.0 5.0
0024 24.2 21.7 26.4 5.5 7.5
0031 31.0 27.7 34.1 7.5 10.0
MR6 0048 48.0 43.8 52.8 11.0 15.0
0062 62.0 57.0 68.2 15.0 20.0
MR7 0075 75.0 69.0 82.5 18.5 25.0
0088 88.0 82.1 96.8 22.0 30.0
0105 105.0 99.0 115.5 30.0 40.0
MR8 0140 143.0 135.1 154.0 37.0 50.0
0170 170.0 162.0 187.0 45.0 60.0
0205 208.0 200.0 225.5 55.0 75.0
MR9 0261 261.0 253.0 287.1 75.0 100.0
0310 310.0 301.0 341.0 90.0 125.0
*See 10.1.3 Overload capability.
VACON · 144 TECHNICAL DATA, VACON® 100 HVAC
10
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205

Vacon 100 Specifications

General

Product type	AC Drive
Enclosure class	IP20
EMC filter	Built-in
Power	0.25 kW - 5.5 kW
Cooling method	Fan
Braking chopper	Optional
