NOTE!
The currents in given ambient temperatures (in chapter 10.2 Vacon® 100 HVAC -
technical data) are achieved only when the switching frequency is equal to or less
than the factory default.
10.1.2 MAINS VOLTAGE 380-500 V
Table 51: The power ratings of Vacon
®
100 HVAC in mains voltage 380-500 V, 50-60 Hz, 3~
Frame Drive type Loadability Motor shaft power
Low* 400 V mains 480 V mains
Continuous
current I
L
[A]
Input current
I
in
[A]
10% overload
current [A]
10% overload
40°C [kW]
10% overload
40°C [Hp]
MR4 0003 3.4 3.4 3.7 1.1 1.5
0004 4.8 4.6 5.3 1.5 2.0
0005 5.6 5.4 6.2 2.2 3.0
0008 8.0 8.1 8.8 3.0 5.0
0009 9.6 9.3 10.6 4.0 5.0
0012 12.0 11.3 13.2 5.5 7.5
MR5 0016 16.0 15.4 17.6 7.5 10.0
0023 23.0 21.3 25.3 11.0 15.0
0031 31.0 28.4 34.1 15.0 20.0
MR6 0038 38.0 36.7 41.8 18.5 25.0
0046 46.0 43.6 50.6 22.0 30.0
0061 61.0 58.2 67.1 30.0 40.0
MR7 0072 72.0 67.5 79.2 37.0 50.0
0087 87.0 85.3 95.7 45.0 60.0
0105 105.0 100.6 115.5 55.0 75.0
MR8 0140 140.0 139.4 154.0 75.0 100.0
0170 170.0 166.5 187.0 90.0 125.0
0205 205.0 199.6 225.5 110.0 150.0
MR9 0261 261.0 258.0 287.1 132.0 200.0
0310 310.0 303.0 341.0 160.0 250.0
See 10.1.3 Overload capability.
TECHNICAL DATA, VACON® 100 HVAC VACON · 145
