description of parameters
vacon • 51
24-hour support +358 (0)40
837 1150 • Email: vacon@vacon.
com
7
414
Fault
reset
(2.2.5.10)
Contact closed:
All faults are reset.
415 Acceleration/Deceleration
prohibited
(2.2.5.14)
Contact closed:
No acceleration or decelera
tion possible until the contact is opened.
416
DC-braking
(2.2.5.15)
Contact closed:
In STOP mode, the DC braking operates until the contact is opened.
50
52
Table of Contents
Default Chapter
3
Table of Contents
3
1 Introduction
5
Requirements
6
Trial Time Period
6
2 Control I/O
7
3 Connection of Signals between Master and Follower Drive (OPT-A7)
8
4 Jumper Setting on the OPT-A7 Board
9
5 Terminal to Function" (TTF) Programming Principle
10
Defining an Input/Output for a Certain Function on Keypad
10
Defining a Terminal for a Certain Function with Ncdrive Programming Tool
11
Defining Unused Inputs/Outputs
12
6 Shaft Synchronization Application - Parameter Lists
13
Monitoring Values (Control Keypad: Menu M1)
13
Basic Parameters (Control Keypad: Menu M2 G2.1)
14
Input Signals
15
Basic Settings (Control Keypad: Menu M2 6.3.2 G2.2.2)
15
G2.2.1)
15
Analogue Input
15
Analogue Input 2 (Control Keypad: Menu M2 G2.2.3)
16
Free Analogue Input, Signal Selection (Keypad: Menu M2 G2.2.4)
16
Digital Inputs (Control Keypad: Menu M2 G2.2.5)
17
Output Signals
18
Delayed Digital Output 1 (Keypad: Menu M2 G2.3.1)
18
Delayed Digital Output 2 (Keypad: Menu M2 G2.3.2)
18
Digital Output Signals (Control Keypad: Menu M2 G2.3.3)
19
Limit Settings (Control Keypad: Menu M2 G2.3.4)
20
Analogue Output 1 (Control Keypad: Menu M2 G2.3.5)
21
Analogue Output 2 (Control Keypad: Menu M2 G2.3.6)
21
Analogue Output 3 (Control Keypad: Menu M2 G2.3.7)
22
Mechanical Brake (Control Keypad: Menu M2 G2.3.8)
22
Drive Control Parameters (Control Keypad: Menu M2 G2.4)
23
Motor Control Parameters (Control Keypad: Menu M2 G2.5)
24
PMSM Settings (Control Keypad: Menu M2 G2.5.19)
25
Protections (Control Keypad: Menu M2 G2.6)
26
Fieldbus Parameters (Control Keypad: Menu M2 G2.7)
28
Torque Control Parameters (Control Keypad: Menu M2 G2.8)
29
Shaft Synchronization Parameters (Control Keypad: Menu M2 G2.9)
30
License Key (Control Keypad: Menu M2 G2.10)
31
Keypad Control (Control Keypad: Menu M3)
31
System Menu (Control Keypad: Menu M6)
31
Expander Boards (Control Keypad: Menu M7)
31
7 Description of Parameters
32
Vacon Shaft Synchronization Application
32
Keypad Control Parameters
85
Application Specific Variables in the Monitor Menu and Fieldbus Interface
86
8 Shaft Synchronization Operation
87
Shaft Synchronization Fieldbus Interface
90
9 Appendices
91
Closed Loop Parameters (ID's 612 to 621)
91
Note on Use of Permanent Magnet Motors ("AC Brushless" Motors)
91
Parameters of Motor Thermal Protection (ID's 704 to 708)
92
Parameters of Stall Protection (ID's 709 to 712)
92
Fieldbus Control Parameters (ID's 850 to 859)
92
10 Shaft Synchronization Application Specific Fault Codes
93
11 Commissioning of Shaft Synchronization Application
93
