909 DI Status
Default: Read-Only
Range: n/a
Level 2 (SIO)
This parameter provides a 15-bit status display.
The following bits are used with this parameter:
910 Vin1 Status
911 Cin Status
912 Vin2 Status
Default: Read-Only
Range: 0.00-100.00%
Level 2 (SIO)
Parameter 910 provides the input percentage applied to the Vin1 terminal; parameter 911 provides the input percentage
applied to the Cin terminal; and parameter 912 provides the input percentage applied to the Vin2 terminal.
913 Output Status
Default: Read-Only
Range: n/a
Level 2 (SIO)
This parameter provides a 10-bit binary status display. A “1” in the status word indicates that the output is active.
The following bits are used with this parameter:
914 Vmet Status
915 Imet Status
Default: Read-Only
Range: 0.00-100.00%
Level 2 (SIO)
Parameter 914 provides the output percentage applied to the Vmet terminal; parameter 915 provides the output
percentage applied to the Imet terminal.
916 Infrared Baud
Default: 9600
Range: n/a
Level 2 (SIO)
This parameter defines the baud rate of the IRDA port.
The following data values may be assigned to this parameter:
Parameter Value
9600
19200
38400
57600
Table 7-2: Description of X5 Parameters (Page 36 of 40)
Bit When Set to 1 Signifies Bit When Set to 1 Signifies Bit When Set to 1 Signifies
10 DI-A Input 5 DI3 Input 0 FWD Input
11 DI-B Input 6 DI4 Input 1 REV Input
12 DI-C Input 7 DI5 Input 2 R/J Input
13 DI-D Input 8 MOL Input 3 DI1 Input
14 DI-E Input 9 EN Input 4 DI2 Input
14131211109876543210
Bit When Set to 1 Signifies Bit When Set to 1 Signifies
5 RB Output 0 R1 Output
6 N/A 1 R2 Output
7 N/A 2 DO1 Output
8 N/A 3 DO2 Output
9 N/A 4 RA Output
9876543210
