Chapter 1: Introduction
1.1 Product Overview
The X5 AC drive provides an economical, powerful solution for a large array of industrial
applications. It features remote communications capability (using Ethernet, Devicenet, Modbus
®
and
Modbus
®
TCP/IP protocols), a keypad for easy configuration, and standard NEMA 4X / IP66 and
NEMA 12 / IP55 enclosures that eliminate the need for mounting in a separate enclosure. A USB
interface allows you to copy parameters from drive to drive, and to download data logs. Like the X4
AC drive, it provides a robust, compact solution for industrial applications, but with more capability.
The X5 product family includes a wide variety of models to suit almost any input voltage
requirement. An ‘x’ in the following table indicates what models are currently available. Refer to
“Chapter 2: Technical Characteristics” on page 14 for help in interpreting model numbers.
1.2 Overview of This Manual
This manual contains specifications, receiving and installation instructions, configuration,
description of operation, options, and troubleshooting procedures for X5 AC drive devices.
For experienced users, a Quick-Start section begins on page 69. A summary of parameters begins on
page iii of this manual.
Horsepower
Input Voltage
115 Vac
1 Phase
230 Vac
3 Phase
460 Vac
3 Phase
575 Vac
3 Phase
1xxx x
2xxx
3xxx
5xxx
7.5 x x x
10 x x x
15 x x x
20 x x x
25 x x x
30 x x x
40 x x
50 x x
60 x x
75 x x
100 x x
125 x x
150 x x
200 x x
