X5 AC Drive User’s Manual Chapter 2: Technical Characteristics
DPD00089A - 18 - © 2009 Vacon Incorporated All Rights Reserved
2.3 Environmental Specifications
2.4 Electrical Specifications
Note: Unit Rated kVA = rated Voltage x rated Current x 1.732
Operating temperature -10 °C to +40 °C (14 °F to 104 °F)
Storage temperature –20 °C to +65 °C (-4 °F to 149 °F)
Humidity 0% to 95% non-condensing
Altitude 1000 m (3300 ft) without derating
Maximum vibration per EN50178 (1g @ 57-150 Hz)
Acoustic noise 80 dba sound power at 1 m (3 ft), maximum
Cooling
1-5 HP models: Natural convection
7.5 to 200.0 HP models: Forced air (temperature-controlled external fan)
The 575 Vac, 5 HP model has a fan.
Input voltage
X5C1x models: 115 Vac, 1 phase, +/- 10% 1 HP
X5C2x models: 200-230 Vac, 3 phase, +/- 15% 1-30 HP
X5C4x models: 380-460 Vac, 3 phase, +/- 15% 1-200 HP
X5C5x models: 575Vac, 3 phase, +/-15% 1-200 HP
Line frequency 50 / 60 Hz ±2 Hz
Source kVA (maximum) 10 times the unit rated kVA, 65kA maximum (see note below)
DC bus voltage for:
Overvoltage trip
Dynamic brake activation
Nominal undervoltage (UV) trip
115/230 Vac models
406 Vdc
388 Vdc
199 Vdc
460 Vac models
814 Vdc
776 Vdc
397 Vdc
575 Vac models
1017 Vdc
970 Vdc
497 Vdc
Control system
V/Hz or Sensorless Vector Control (SVC)
Carrier frequency = 1 - 16 kHz, programmable; 8 kHz max. for 125-200 HP
models
Output voltage 3-phase: 0 to 100% of incoming voltage (0-230 Vac for 115 Vac models)
Overload capacity
120% of rated RMS current for 60 seconds (normal duty rating)
150% of rated RMS current for 60 seconds (heavy duty rating)
Frequency range 0.1 to 400 Hz
Frequency stability 0.1 Hz (digital), 0.1% (analog) over 24 hours +/- 10 °C
Frequency setting
By keypad, or by external signal (0 to 5 Vdc; 0 to 10 Vdc; 0/4 to 20 mA) or by
pulse train up to 100kHz
