Chapter 2: Technical Characteristics
2.1 Interpreting Model Numbers
The model number of the X5 AC drive appears on the shipping carton label and on the technical data
label on the model. The information provided by the model number is shown below:
X5 C 2 0030 C 09
X5 Series
Torque:
C = Constant - Normal duty
Input Voltage:
2 = 230 Vac, Three-phase
4 = 460 Vac, Three-phase
5 = 575 Vac, Three-phase
Horsepower:
Examples: 0030 = 3 HP; 0300 = 30 HP
Enclosure:
C = NEMA 4X / IP66
D = NEMA 12 / IP55
Optional configuration
(see following section for more information)
X5 Models without option card capability
Smaller horsepower models (30 HP or less) of X5 drives with optional configuration -09 have the
same electrical capabilities as the other X5 models, but do not support option cards. These smaller-
frame models are offered in smaller enclosures (frame size 0, 1, and 2). Table 2-1 shows the model
and size relationships of all the X5 drives.
